DE-2002 デジタルマルチメータ

DCV, ACV, DCA, ACA, DCμA, ACμA, DCmA, ACmA
Resistance, Diode, Buzzer, Capacitance
4300 Counts

モデル : DE-2002

数量 :

Measurement Functions：DCV, ACV, DCA, ACA, DCμA, ACμA, DCmA, ACmA, Resistance, Diode, Buzzer, Capacitance
LCD Display：3 3/4 Digits With 4300 Counts
Sampling Rate：Approx. 2 times per second
Range：Automatic & manual
Overload：”OL” Display On LCD
Low Battery： Display on LCD
Auto Power Off：In 20 Minutes Approx.
Battery：AAA 1.5V x2
EMC standard：EN 55011:1998 Group 1 Class B
EN 61326-1; 1997+A1; 1998
Safety standard：IEC 61010-1 (2001) CAT.III 600V

Measurement Ranges：

23°C ± 5°C max. 80%R.H. Accuracy: ±(%rdg +dgt)

Measurement	Range	Resolution	Accuracy			Input Impedance	Max. Input Voltage	Open-Loop Voltage
			DE-2001	DE-2002	DE-2003
(DCV)	400mV	0.1mV	0.5%+1	0.5%+1	0.3%+1	>100MΩ	600V	────
	4V	0.001V				11MΩ
	40V	0.01V	0.75%+1			10MΩ
	400V	0.1V
	600V	1V
(ACV)	4V	0.001V	1%+5		0.75%+5	11MΩ; <50pF	600V rms	────
	40V	0.01V				10MΩ; <50pF
	400V	0.1V
	600V	1V
	400Ω	0.1Ω	0.75%+2			────	600V	<3.4V
	4kΩ	0.001kΩ	0.75%+1					<1.0V
	40kΩ	0.01kΩ						<0.7V
	400kΩ	0.1kΩ
	4MΩ	0.001MΩ	2%+1
	40MΩ	0.01MΩ	5%+2
(BUZZER)	400Ω	0.1Ω	The buzzer turns on for resistances lower than ≦50±20Ω.			────	600V	<3.4V
(DIODE)	2V	0.01V	1%+1 (for measuring currents smaller than 1.0mA)			────	600V	<3.4V
